Thông số kỹ thuât:
- General specifications
- Speaker type: Full-range, Bass-reflex
- Frequency range (-10dB): 80Hz – 20kHz (Half-space:2π)
- Nominal coverage: 130° conical (Half-space:2π)
- Components: LF: – / HF: – / LF-HF: 4″ full-range
- Power rating: NOISE: 30W / PGM: 60W / PEAK: 120W
- Nominal impedance: 8Ω
- Transformer taps: 100V: 87dB SPL (Half-space:2π) / 70V: 30W (170Ω), 15W (330Ω), 7.5W (670Ω), 3.8W (1.3kΩ)
- SPL: Sensitivity (1W; 1m on axis): 87dB SPL (Half-space:2π) / Peak (Calculated): 108dB SPL (1m, Calculated based on power rating and sensitivity, exclusive of power compression)
- I/O connectors: 1 x Euroblock (4P) : (Input: + / -, Loop Thru: + / -)
- Finish: VXC4: Black / VXC4W: White
- Dimensions: Diameter: 225mm (8.9″) / D: 195mm (7.7″)
-
Net weight: 2.6kg (5.7lbs)
- Cutout size: Ø186 mm (Ø7-5/16″)
- Required ceiling board thickness: 5 mm – 35 mm
- Accessories: O-ring, Tile Rail, Cutout Template
- Packaging: Packaged in pairs
-
Certificate: UL1480, UL2043, NFPA70, CE, EAC, RoHS
- Options: PK-C4B / PK-C4W: Pendant-mount kit
