Thông số kỹ thuât:
- General specifications
- Speaker type: 2-way, Acoustic suspension
- Frequency range (-10dB): 56Hz – 20kHz (Half-space:2π)
- Nominal coverage: 110° conical (Half-space:2π)
- Components: LF: 6.5″ Cone / HF: 0.75″ Soft dome / LF-HF: –
- Power rating: NOISE: 75W / PGM: 150W / PEAK: 300W
- Nominal impedance: 8Ω
- Transformer taps: 100V: 60W (170Ω), 30W (330Ω), 15W (670Ω) / 70V: 60W (83Ω), 30W (170Ω), 15W (330Ω), 7.5W (670Ω)
- SPL: Sensitivity (1W; 1m on axis): 86dB SPL (Half-space:2π) / Peak (Calculated): 111dB SPL (1m, Calculated based on power rating and sensitivity, exclusive of power compression)
- I/O connectors: 1 x Euroblock (4P) : (Input: + / -, Loop Thru: + / -)
- Finish: VXC6: Black / VXC6W: White
- Dimensions: Diameter: 286mm (11.3″) / D: 205mm (8.1″)
-
Net weight: 4.4kg (9.7lbs)
- Cutout size: Ø247 mm (Ø9 3/4″)
- Required ceiling board thickness: 5 mm – 35 mm
- Accessories: O-ring, Tile Rail, Cutout Template
- Packaging: Packaged in pairs
-
Certificate: UL1480, UL2043, NFPA70, CE, EAC, RoHS
- Options: –
