Thông số kỹ thuật:
- General specifications
- Speaker type: 2-way, Bass-reflex
- Frequency range (-10dB): 62Hz – 20kHz
- Nominal coverage: H: 120° / V: 120°
- Components: LF: 5.25″ Cone / HF: 0.75″ Soft dome
- Crossover: 3kHz
- Power rating: NOISE: 75W / PGM: 150W
- Nominal impedance: 8Ω
- Transformer taps: 100V: 30W (330Ω), 15W (670Ω), 7.5W (1.3kΩ) / 70V: 30W (170Ω), 15W (330Ω), 7.5W (670Ω), 3.8W (1.3kΩ)
- SPL: Sensitivity (1W; 1m on axis): 89dB SPL / Peak (Calculated): 114dB SPL
- I/O connectors: 1x Euroblock (4P) (Input: + / -, Loop Thru: + / -)
- Shape: Rectangular
- Cabinet material: ABS
- Finish: VXS5:Black / VXS5W:White
- Waterproof: IP35
- Dimensions: W: 176mm (6.9″) / H: 280mm (11.0″) / D: 163mm (6.4″)
- Net weight: 3.6kg (7.9lbs)
- Accessories: Wall / Ceiling mount bracket, Terminal cover
- Others: Packaged in pairs
- Certificate: UL1480, NFPA70, CE, EAC, RoHS
- EN54-24 compliance: –
